Industry pain points and demands

When silicon wafers overlap on the carrier, the suction cup of the robot in the loading and unloading process will crush the silicon wafers, causing damage to the silicon wafers. If fragments and foreign objects enter, it will easily contaminate the vacuum chamber after the high-temperature process, affecting production and increasing maintenance costs. Therefore, it is necessary to control the overlapping of silicon wafers on the carrier.


· Overlapping Wafers: Misalignment and overlapping during robot handling cause wafer breakage, leading to increased defects.

· Contamination Hazards: Fragments and foreign particles from broken wafers risk contaminating the vacuum chamber, disrupting production and escalating maintenance costs.

· High-Temperature Sensitivity: Misaligned wafers in high-temperature processes can lead to further damage and operational inefficiencies.





Contact Now

Physical Picture or Imaging Effect Picture

Physical picture

SinceVision Solution: SRI7700 3D Laser Profiler

01Ultra-High Resolution Detection: Identifies wafer overlap and edge misalignment with exceptional clarity to improve placement accuracy.
02Compact and Integrated Design: Eliminates the need for a separate controller, reducing installation space by over 50% while maintaining efficiency.
03High Detection Accuracy: Achieves a missed detection rate as low as 0.002%, minimizing defects and maximizing throughput.
